Neapco 22-1162 35 Series Shear Yoke 1.5″
221162
Please use the downloadable catalog to select your Neapco U-joint part numbers
Please use the downloadable Dimension Guide to select your Neapco U-joint part numbers
Please use the downloadable catalog to select your Neapco driveline part numbers
Please use the downloadable catalog to select your Neapco PTO driveline part numbers
22-1162
DL SERIES:L35N 2200 35
BORE TYPE:ROUND
BORE DIAMETER:1.5″
CENTER LINE TO END OF HUB:4.188″
HUB DIAMETER:
KEYWAY LOCATION:
KEYWAY WIDTH:
LENGTH THRU BORE:
SET SCREW DISTANCE TO END OF HUB:11/16″
SET SCREW HOLE SIZE:1/2″ THRU DRILLED
Set Screw Location:GAP
SPLINE /NO TEETH:
FITS TUBING:
Notes:
Cross References:
G&G Manufacturing Co:196-3524, Parts Master:21236, Weasler:802-35224, Weasler:802-3524
