Description
BRAND NEW
PIONEER TS-B401PRO
PRO Series | 4-Inch 600 Watts Max 4-Ohms Titanium Bullet Tweeter
Key Features:
- 600 Watts Max Power (300 Watts Nominal)
- Titanium Diaphragm and Aluminum Die-Cast Chassis
- Designed for High Sensitivity and High Power Handling
- Package Contains 1 Unit
System Specs:
- System Type: Bullet Tweeter
- Sound Pressure Level (Sensitivity): 106dB
- Frequency Range: 2,500 Hz to 22 kHz
- Continuous Power Handling (RMS): 300 Watts
- Maximum Peak Power Handling: 600 Watts
- Nominal Impedance: 4 ohms
Tweeter Specs:
- Type: Bullet Tweeter
- Size (mm – in.): 103mm – 4″
- Diaphragm Material: Titanium
- Magnet Material: Ferrite
- Magnet Weight: 15.2 oz
- Wave Guides: Horn
- Unit Size (mm – in.): 116mm – 4-5/8″
- Cut Out Dimensions (mm – in.): 95mm – 3-3/4″
- Mounting Depth (mm – in.): 68mm – 2-5/8″
- Protrusion (mm – in.): 9mm – 3/8″
