Description
Rockford fosgate M2 750 Watt 5-Channel Element Ready™ Amplifier
Product details
Designed to withstand the elements, the R2-750X5 amplifier is an Element Ready™ 750 watt, full-range class-D model, capable of operating at 4Ω or 2Ω stereo, and 4Ω bridged/mono with a subwoofer channel that can be run at 4Ω or 2Ω. This amplifier is extremely efficient because of its class D technology which reduces demand on the electrical system. The amp also features C.L.E.A.N. circuitry to help you adjust your gain settings, a P.O.W.E.R. Supply that generates more power as voltage increases, and integrated Punch EQ that corrects for acoustic deficiencies while delivering up to 3X the bass.
FEATURES AT A GLANCE
- C.L.E.A.N. input/output clip detection and indicator LEDs
- Conformal coated circuit board protects against dust and water
- Optimized using AudioGraph PowerCube measurement tool
- Zinc Nickel-plated Marine grade brass connection terminals
- Fully Adjustable 12 dB/octave High and Low pass Butterworth Crossovers
- Element Ready™ design protects against outdoor exposure
- Integration with OEM and Aftermarket Radios
- RATS (Rockford Automated Testing System) proprietary quality & performance tested
- Low Impedance Stability
- Auto-Sense bypass switch for vehicles with RAP (Retained Accessory Power)
- Continuously Variable On Board Punch EQ
- Short Circuit & Over Current Protection
- Top Mounted Control Panel
- Includes RLC Remote Level Control
- 2/4/5 Channel Input Selection Switch
- Balanced Differential Inputs eliminates noise picked up by signal cables
- Variable Infrasonic Filter
- UV stable powder coated cast aluminum heatsink
- Integrated Power and Speaker Terminals
- Focused mass heat sink allows critical aluminum material to be located around hottest internal devices
- “Auto-Sense” turn-on with remote out (high level in)
- CEA-2006 Compliant & CE Compliant
- 2-Year Warranty
- Rollback Protection
Specifications
Cta-2006 Compliant
Number of Channels5Total Power
(Sum of Rated Power)750 WattsRated Power
(RMS Continuous Power)50 Watts x 4 + 200 Watts x 1 @ 4Ω
100 Watts x 4 + 350 Watts x 1 @ 2Ω
200 Watts x 2 + N/A @ 4Ω Bridged/MonoDynamic Power
(PVC/PowerCube®)70 Watts x 4 + 241 Watts x 1 @ 4Ω
114 Watts x 4 + 426 Watts x 1 @ 2Ω
234 Watts x 2 + N/A @ 4Ω Bridged/MonoBridgeableYesFrequency Response20 Hz – 20 kHzInput SensitivityLow-Level: 150 mV – 4 V
High-Level: 450 mV – 12 VCircuit Topology ClassClass DEfficiency (average)
Total Harmonic Distortion (THD+Noise)4Ω: <1.0%
2Ω: <1.0%Signal InputFront Low-Level: 2 RCA
Front High-Level: 4-Pin Molex
Rear Low-Level: 2 RCA
Rear High-Level: 4-Pin Molex
Sub Low-Level: 2 RCA
Sub High-Level: 4-Pin MolexSignal OutputN/ATone Controls0 to +18 dB @ 45 HzCrossover ControlsFront High-Pass:
50 Hz – 250 Hz @ 12dB/Octave Butterworth
Front Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave Butterworth
Rear High-Pass:
50 Hz – 250 Hz @ 12dB/Octave Butterworth
Rear Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave Butterworth
Sub Low-Pass:
50 Hz – 250 Hz @ 12dB/Octave Butterworth
Sub Infrasonic:
15 Hz – 40 Hz @ 12dB/Octave ButterworthRemote ControlsYesVisual IndicatorsPower/Protect
C.L.E.A.N. In
C.L.E.A.N. Out (front)
C.L.E.A.N. Out (rear)
C.L.E.A.N. Out (sub)Power Wire Gauge4 AWGPower Input ConnectorCompression Terminal BlockSpeaker Wire Gauge8 AWGSpeaker Output ConnectorCompression Terminal BlockCoolingConvectionHeatsink
Operating Voltage9 – 16 VDCRecommended Fuse
(not included)120 AAverage Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)71 ASuggested Alternator
Included In The Box
Dimensions (H x W x D)1.9″ x 6.8″ x 11.2″
(4.9 cm x 17.3 cm x 28.5 cm)Shipping Weight6.13 Lbs. (2.78 Kg)
